Unifi 5G beinir með WiFi 7 – UDR-5G-Max

$ 90.98

Category:

Lýsing Dimensions 110 x 110 x 250 mm (4.3 x 4.3 x 9.8″) UniFi Application Suite Network ✓ Protect ✓ Access ✓ Talk ✓ Connect ✓ Managed UniFi Devices 30 Managed Cameras (5) HD (2) 2K (1) 4K Simultaneous Users Connected 300 Max. WAN Port Count 4 Default WAN Ports (1) 10G SFP (1) 2.5 GbE RJ45 Port Layout 2.5 GbE RJ45 4 (1 PoE) (2.5G/1G/100M) 10G SFP 1 (10G/1G) IDS/IPS Throughput 2.3 Gbps Form Factor Desktop Coverage Area 160 m² (1,750 ft²) Security Stateful Firewall ✓ Application-Aware Layer 7 Firewall ✓ DPI & Traffic Identification ✓ Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) ✓ Content Filtering ✓ Intrusion Prevention (IPS/IDS) ✓ Ad Blocking ✓ IDS/IPS Signatures 20,000 with CyberSecure VPN & SD-WAN License-Free SD-WAN ✓ Site-to-Site VPN Site Magic ✓ IPsec ✓ OpenVPN ✓ VPN Server Identity Endpoint One-Click VPN ✓ Teleport Zero-Configuration VPN ✓ WireGuard ✓ OpenVPN ✓ L2TP ✓ VPN Client OpenVPN ✓ WireGuard ✓ Site-to-Site VPN Single Tunnel Throughput Site Magic 20 VPN Client Single Tunnel Throughput WireGuard 8 OpenVPN 8 Networking Multi-WAN Load Balancing ✓ Dynamic Routing OSPF ✓ Advanced QoS ✓ Multicast DNS (mDNS) ✓ Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) ✓ Integrated RADIUS Server ✓ RADIUS over TLS (RadSec) ✓ Additional Internet Failover with UniFi LTE Backup ✓ Internet Quality and Outage Reporting ✓ MAC Address Table Size 2,000 Virtual Network Override ✓ Integrated WiFi WiFi Standard 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) Throughput 6 GHz 5.7 Gbps 5 GHz 4.3 Gbps 2.4 GHz 688 Mbps MIMO 6 GHz 2 x 2 (DL/UL MU-MIMO) 5 GHz 2 x 2 (DL/UL MU-MIMO) 2.4 GHz 2 x 2 (DL/UL MU-MIMO) Antenna Gain 6 GHz 8 dBi 5 GHz 5 dBi 2.4 GHz 4 dBi Max. TX Power 6 GHz 22 dBm 5 GHz 26 dBm 2.4 GHz 23 dBm Wireless Security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) Max. BSSIDs 4 per Radio Supported Data Rates 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320) 802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) 802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15 , HT 20/40) 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps Cellular 5G NR Category 5G NR Sub-6 Frequency Bands n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n38, n40, n41, n48, n66, n70, n71, n75, n76, n77, n78, n79 Max. TX Power HPUE power class 2: 26 dBm 4G LTE Frequency Bands B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B18, B19, B20, B21, B25, B26, B28, B29, B30, B32, B34, B38, B39, B40, B41, B42, B43, B46, B48, B66, B71 Max. TX Power HPUE power class 2: 25 dBm 3G UMTS Frequency Bands B1, B2, B4, B5, B8, B19 Peak Data Speed 5G NSA Downlink 3.4 Gbps Uplink 560 Mbps 5G SA Downlink 1.8 Gbps Uplink 650 Mbps 4G LTE Downlink 1.6 Gbps Uplink 210 Mbps Antenna Gain 617-960 MHz: 3 dBi 1710-2700 MHz: 7 dBi 3300-5000 MHz: 8 dBi 5150~5925 MHz: 8 dBi SIM (2) Nano SIM (1) Nano-SIM or eSIM Hardware NVR Storage Pre-installed 64 GB microSD for NVR Expansion Slot MicroSD Card PoE Budget 15.4W Max. PoE Wattage per Port by PSE 15.4W Voltage Range PoE Mode 44-57V Max. Power Consumption 34.5W (Excluding PoE output) Power Method DC jack (54V DC/1.1A) Power Supply 54V DC/1.1A (Adapter included) Supported Voltage Range 100—240V AC Heat Dissipation 115 BTU/hr (Excluding PoE output) Processor Quad-core ARM® Cortex®-A53 at 1.5 GHz System Memory 3 GB Weight 1.4 kg (3.1 lb) Enclosure Material Polycarbonate LCM Display 4.7″ touchscreen Management Ethernet Bluetooth LEDs Ethernet ✓ SFP ✓ System ✓ Button (1) Factory-reset ESD/EMP Protection Air: ± 8kV, contact: ± 4kV Ambient Operating Temperature 0 to 40° C (22 to 104° F) Ambient Operating Humidity 5 to 95% noncondensing NDAA Compliant ✓ Certifications FCC, IC, CE, GCF, PTCRB, AT&T, T-Mobile, Verizon, Wi-Fi Alliance®
